Machine Learning Project: Digit Recogniser (Kaggle)
Tensorflow implementation of digit recognition
Data from Kaggle Digit Recognition competition
https://www.kaggle.com/c/digit-recognizer/data
%matplotlib inline
import numpy as np
import pandas as pd
import matplotlib.pyplot as plt
from keras.models import Sequential
from keras.layers import Dense, Activation
Using TensorFlow backend.
Load data
train_file = 'train.csv'
test_file = 'test.csv'
train_df = pd.read_csv(train_file)
test_df = pd.read_csv(test_file)
train_df.head() # labels and pixels
| label | pixel0 | pixel1 | pixel2 | pixel3 | pixel4 | pixel5 | pixel6 | pixel7 | pixel8 | ... | pixel774 | pixel775 | pixel776 | pixel777 | pixel778 | pixel779 | pixel780 | pixel781 | pixel782 | pixel783 | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | ... | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | ... | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| 2 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | ... | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| 3 | 4 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | ... | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| 4 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | ... | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
5 rows × 785 columns
test_df.head() # no labels here
| pixel0 | pixel1 | pixel2 | pixel3 | pixel4 | pixel5 | pixel6 | pixel7 | pixel8 | pixel9 | ... | pixel774 | pixel775 | pixel776 | pixel777 | pixel778 | pixel779 | pixel780 | pixel781 | pixel782 | pixel783 | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | ... | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | ... | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| 2 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | ... | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| 3 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | ... | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| 4 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | ... | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
5 rows × 784 columns
So each row of the dataset is a sequence of ink intensity for the 784 pixels that represents square image with the size 28x28.
train_labels = train_df.label
train_images = train_df.iloc[:,1:]
test_images = test_df
Show some digits from the input dataset
plt.figure(figsize=(12,6))
for i in range(0,9):
plt.subplot(250 + (i+1))
img = train_images.iloc[i,:].values.reshape(28, 28)
plt.imshow(img, cmap='Blues')
plt.title(train_labels[i])
Preprocess data for NN
train_images = (train_images/train_images.max()).fillna(0) # normalize values
test_images = (test_images/test_images.max()).fillna(0) # normalize values
train_labels = pd.get_dummies(train_labels) # one-hot encoding of the label
train_labels.head()
| 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | |
|---|---|---|---|---|---|---|---|---|---|---|
| 0 | 0 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| 1 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| 2 | 0 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| 3 | 0 | 0 | 0 | 0 | 1 | 0 | 0 | 0 | 0 | 0 |
| 4 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
Build simple 1-hidden layer dense NN
Some more information about Keras’ Sequential models
https://keras.io/getting-started/sequential-model-guide/
model = Sequential([
Dense(32, input_dim=784),
Activation('relu'),
Dense(10),
Activation('softmax')
])
# Multi-class classification problem
model.compile(optimizer='rmsprop',
loss='categorical_crossentropy',
metrics=['accuracy'])
model.summary()
_________________________________________________________________
Layer (type) Output Shape Param #
=================================================================
dense_1 (Dense) (None, 32) 25120
_________________________________________________________________
activation_1 (Activation) (None, 32) 0
_________________________________________________________________
dense_2 (Dense) (None, 10) 330
_________________________________________________________________
activation_2 (Activation) (None, 10) 0
=================================================================
Total params: 25,450
Trainable params: 25,450
Non-trainable params: 0
_________________________________________________________________
# import pydot
# from keras.utils.visualize_util import plot
# plot(model, to_file='model.png')
Train the model
print(train_images.values.shape)
print(train_labels.values.shape)
(42000, 784)
(42000, 10)
Let’s fit the weights of our NN. To estimate overfitting, let’s use validation dataset which we set up as 5% of the training dataset - validation_split = 0.05.
history=model.fit(train_images.values, train_labels.values, validation_split = 0.05,
nb_epoch=25, batch_size=64)
E:\IDE\WPy-3662\python-3.6.6.amd64\lib\site-packages\ipykernel_launcher.py:2: UserWarning: The `nb_epoch` argument in `fit` has been renamed `epochs`.
Train on 39900 samples, validate on 2100 samples
Epoch 1/25
39900/39900 [==============================] - 3s 81us/step - loss: 0.4539 - acc: 0.8785 - val_loss: 0.3141 - val_acc: 0.9143
Epoch 2/25
39900/39900 [==============================] - 3s 64us/step - loss: 0.2465 - acc: 0.9286 - val_loss: 0.2520 - val_acc: 0.9348
Epoch 3/25
39900/39900 [==============================] - 3s 70us/step - loss: 0.2031 - acc: 0.9421 - val_loss: 0.2269 - val_acc: 0.9424
Epoch 4/25
39900/39900 [==============================] - 3s 65us/step - loss: 0.1752 - acc: 0.9490 - val_loss: 0.2058 - val_acc: 0.9429
Epoch 5/25
39900/39900 [==============================] - 3s 67us/step - loss: 0.1562 - acc: 0.9545 - val_loss: 0.1911 - val_acc: 0.9481
Epoch 6/25
39900/39900 [==============================] - 3s 66us/step - loss: 0.1414 - acc: 0.9586 - val_loss: 0.1873 - val_acc: 0.9486
Epoch 7/25
39900/39900 [==============================] - 3s 71us/step - loss: 0.1306 - acc: 0.9613 - val_loss: 0.1816 - val_acc: 0.9533
Epoch 8/25
39900/39900 [==============================] - 3s 63us/step - loss: 0.1202 - acc: 0.9647 - val_loss: 0.1698 - val_acc: 0.9552
Epoch 9/25
39900/39900 [==============================] - 3s 67us/step - loss: 0.1114 - acc: 0.9671 - val_loss: 0.1710 - val_acc: 0.9543
Epoch 10/25
39900/39900 [==============================] - 2s 61us/step - loss: 0.1052 - acc: 0.9692 - val_loss: 0.1703 - val_acc: 0.9581
Epoch 11/25
39900/39900 [==============================] - 3s 66us/step - loss: 0.0993 - acc: 0.9710 - val_loss: 0.1605 - val_acc: 0.9590
Epoch 12/25
39900/39900 [==============================] - 3s 70us/step - loss: 0.0937 - acc: 0.9724 - val_loss: 0.1620 - val_acc: 0.9576
Epoch 13/25
39900/39900 [==============================] - 3s 78us/step - loss: 0.0884 - acc: 0.9736 - val_loss: 0.1523 - val_acc: 0.9624
Epoch 14/25
39900/39900 [==============================] - 3s 71us/step - loss: 0.0840 - acc: 0.9757 - val_loss: 0.1536 - val_acc: 0.9610
Epoch 15/25
39900/39900 [==============================] - 3s 78us/step - loss: 0.0802 - acc: 0.9763 - val_loss: 0.1642 - val_acc: 0.9557
Epoch 16/25
39900/39900 [==============================] - 3s 80us/step - loss: 0.0766 - acc: 0.9780 - val_loss: 0.1610 - val_acc: 0.9562
Epoch 17/25
39900/39900 [==============================] - 3s 70us/step - loss: 0.0731 - acc: 0.9785 - val_loss: 0.1608 - val_acc: 0.9581
Epoch 18/25
39900/39900 [==============================] - 3s 75us/step - loss: 0.0703 - acc: 0.9791 - val_loss: 0.1611 - val_acc: 0.9614
Epoch 19/25
39900/39900 [==============================] - 3s 71us/step - loss: 0.0680 - acc: 0.9797 - val_loss: 0.1630 - val_acc: 0.9633
Epoch 20/25
39900/39900 [==============================] - 3s 76us/step - loss: 0.0647 - acc: 0.9809 - val_loss: 0.1575 - val_acc: 0.9624
Epoch 21/25
39900/39900 [==============================] - 3s 63us/step - loss: 0.0631 - acc: 0.9816 - val_loss: 0.1624 - val_acc: 0.9600
Epoch 22/25
39900/39900 [==============================] - 2s 63us/step - loss: 0.0599 - acc: 0.9826 - val_loss: 0.1659 - val_acc: 0.9590
Epoch 23/25
39900/39900 [==============================] - 3s 63us/step - loss: 0.0579 - acc: 0.9824 - val_loss: 0.1617 - val_acc: 0.9619
Epoch 24/25
39900/39900 [==============================] - 2s 60us/step - loss: 0.0558 - acc: 0.9833 - val_loss: 0.1745 - val_acc: 0.9586
Epoch 25/25
39900/39900 [==============================] - 2s 59us/step - loss: 0.0535 - acc: 0.9839 - val_loss: 0.1684 - val_acc: 0.9595
hist_df = pd.DataFrame(history.history)
hist_df.head()
| val_loss | val_acc | loss | acc | |
|---|---|---|---|---|
| 0 | 0.314067 | 0.914286 | 0.453909 | 0.878546 |
| 1 | 0.251983 | 0.934762 | 0.246468 | 0.928571 |
| 2 | 0.226936 | 0.942381 | 0.203141 | 0.942080 |
| 3 | 0.205757 | 0.942857 | 0.175246 | 0.948972 |
| 4 | 0.191095 | 0.948095 | 0.156158 | 0.954486 |
fig = plt.figure(figsize=(14,6))
plt.style.use('bmh')
params_dict = dict(linestyle='solid', linewidth=0.25, marker='o', markersize=6)
plt.subplot(121)
plt.plot(hist_df.loss, label='Training loss', **params_dict)
plt.plot(hist_df.val_loss, label='Validation loss', **params_dict)
plt.title('Loss for ' + str(len(history.epoch)) + ' epochs')
plt.xlabel('Epoch')
plt.ylabel('Loss')
plt.legend()
plt.subplot(122)
plt.plot(hist_df.acc, label='Training accuracy', **params_dict)
plt.plot(hist_df.val_acc, label='Validation accuracy', **params_dict)
plt.title('Accuracy for ' + str(len(history.epoch)) + ' epochs')
plt.xlabel('Epoch')
plt.ylabel('Accuracy')
plt.legend()
<matplotlib.legend.Legend at 0xe4d7fd0>
Some conclusions here:
- At some number of the epochs (8-10 in this case) the validation loss stops decreasing, i.e. the network begin to overfit. The training loss still decreases.
- The same is true for the training/validation accuracy - validation accuracy stops increasing after some number of epochs.
- Since validation data was not used for training, measuring accuracy on the the validation dataset gives us an estimation of the ability of the model to generalize.
Basically we tuned the only one parameter - number of epochs using validation. Now I will use epochs=10.
# Predict on the whole dataset now, 10 epochs
model = Sequential([
Dense(32, input_dim=784),
Activation('relu'),
Dense(10),
Activation('softmax')
])
# Multi-class classification problem
model.compile(optimizer='rmsprop',
loss='categorical_crossentropy',
metrics=['accuracy'])
model.fit(train_images.values, train_labels.values, nb_epoch=10, batch_size=64)
E:\IDE\WPy-3662\python-3.6.6.amd64\lib\site-packages\ipykernel_launcher.py:14: UserWarning: The `nb_epoch` argument in `fit` has been renamed `epochs`.
Epoch 1/10
42000/42000 [==============================] - 3s 69us/step - loss: 0.4778 - acc: 0.8690
Epoch 2/10
42000/42000 [==============================] - 3s 71us/step - loss: 0.2596 - acc: 0.9256
Epoch 3/10
42000/42000 [==============================] - 3s 67us/step - loss: 0.2147 - acc: 0.9383
Epoch 4/10
42000/42000 [==============================] - 3s 73us/step - loss: 0.1843 - acc: 0.9471
Epoch 5/10
42000/42000 [==============================] - 3s 77us/step - loss: 0.1621 - acc: 0.9524
Epoch 6/10
42000/42000 [==============================] - 3s 66us/step - loss: 0.1459 - acc: 0.9574
Epoch 7/10
42000/42000 [==============================] - 3s 65us/step - loss: 0.1321 - acc: 0.9615
Epoch 8/10
42000/42000 [==============================] - 3s 62us/step - loss: 0.1219 - acc: 0.9647
Epoch 9/10
42000/42000 [==============================] - 3s 66us/step - loss: 0.1127 - acc: 0.9678
Epoch 10/10
42000/42000 [==============================] - 3s 67us/step - loss: 0.1060 - acc: 0.9693
<keras.callbacks.History at 0xe779390>
Predict test labels
pred_classes = model.predict_classes(test_images.values)
pred_classes
array([2, 0, 9, ..., 3, 9, 2], dtype=int64)
pred = pd.DataFrame({'ImageId': range(1, len(pred_classes)+1), 'Label': pred_classes})
pred.head()
| ImageId | Label | |
|---|---|---|
| 0 | 1 | 2 |
| 1 | 2 | 0 |
| 2 | 3 | 9 |
| 3 | 4 | 4 |
| 4 | 5 | 3 |
pred.tail()
| ImageId | Label | |
|---|---|---|
| 27995 | 27996 | 9 |
| 27996 | 27997 | 7 |
| 27997 | 27998 | 3 |
| 27998 | 27999 | 9 |
| 27999 | 28000 | 2 |
pred.to_csv('subm06.csv', index=False)
